구축환경
GNS3 - (https://www.gns3.com/software/download)
OSPF와 EIGRP 재분배연결
OSPF 라우터
Router#conf t
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)#router ospf 1
Router(config-router)#redistribute eigrp 100
% Only classful networks will be redistributed
Router(config-router)#redistribute eigrp 100 ?
metric Metric for redistributed routes
metric-type OSPF/IS-IS exterior metric type for redistributed routes
subnets Consider subnets for redistribution into OSPF (모든 서브넷들을 재분배하겠다)
tag Set tag for routes redistributed into OSPF
<cr>
Router(config-router)#redistribute eigrp 100 subnets
Router(config-router)#exit
Router(config)#router eigrp 100
Router(config-router)#redistribute ospf 1 metric 1544 2000 255 1 1500
Router(config-router)#network 30.30.30.0 255.255.255.0
Router(config-router)#no auto-summary
EIGRP 라우터
Router(config)#router eigrp 100
Router(config-router)#net 30.30.30.0 255.255.255.0
Router(config-router)#
%DUAL-5-NBRCHANGE: IP-EIGRP 100: Neighbor 30.30.30.60 (Serial0/2/0) is up: new adjacency
[OSPF - RIP 재분배]
conf t
router ospf 1
Router(config-router)#redistribute rip subnets
Router(config-router)#exit
Router(config)#router rip
Router(config-router)#version 2
Router(config-router)#redistribute ospf 1 metric 10
Router(config-router)#network 3.3.3.128
